233kwh Home Br Solar Carton and Pallet Energy Storage Solution

1 / 5

233kwh Home Br Solar Carton and Pallet Energy Storage Solution

Customization:	Available
After-sales Service:	After- Sales Service
Warranty:	3 Years, 5 Years

Send Inquiry

Product Description

■ Basic Info.

Condition

New

Certification

ISO, CE

Application

Home, Industrial, Commercial, School, Factory

Specification

100kwh, 233kwh

Type of Cell

Lithium Iron Phosphate(LFP)

Cell Parameter

3.2V/314ah

Cooling

Liquid Cooling

Protection Class

IP55

Max.Charge/Discharge Power

0.5c

Configuration of System

1p416sx12

Rated Capacity

5.01 Mwh

Rated Voltage

1331.2V

Voltage Range

1164.8~1497.6V

Origin

China

HS Code

8501310000

Production Capacity

1000set/Month

■ Packaging & Delivery

Package Size

110.00cm * 140.00cm * 238.00cm

Package Gross Weight

2000.000kg

Transport Package

Carton and Pallet

■ Product Description

Items	Parameters
Type of cell	Lithium Iron Phosphate(LFP)
Cell parameter	3.2V/314Ah
Max. charge/discharge power	0.5C
Configuration of system	1P416S×12
Rated capacity	5.01 MWh
Rated voltage	1331.2V
Voltage range	1164.8~1497.6V
Cooling method	Liquid Cooling
Operating temperature	−30~50ºC
Humidity	≤95%RH, no condensation
Altitude	≤3000m
Noise level	≤80dB(A), @1m / 75dB(optional)
IP grade	IP55
Storage temperature	−20~45ºC
Corrosion-proof grade	C4/C5(optional)
Fire protection	Temperature sensor + Smoke detector + Combustible gas detector + Deflagration venting + Fire extinguishing gas + Water sprinkler
External communication interface	Ethernet/CAN/RS485
Dimension(L×W×H)	6058×2438×2896mm
Weight	≈42000 kg

■ Frequently Asked Questions

What type of battery technology is used in this system?

This system utilizes Lithium Iron Phosphate (LFP) cells, which are known for their high safety profile, long cycle life, and thermal stability.

Is this energy storage solution suitable for outdoor use?

Yes, the system is designed with an IP55 protection class and has an operating temperature range of -30°C to 50°C, making it suitable for various environments.

How is the battery temperature managed?

The system features an advanced Liquid Cooling method to ensure efficient heat dissipation and maintain optimal battery performance.

What fire safety measures are included?

Safety is a priority. The system includes temperature sensors, smoke detectors, combustible gas detectors, deflagration venting, fire extinguishing gas, and a water sprinkler system.

What are the primary applications for this 5.01 MWh system?

This large-scale storage solution is ideal for industrial, commercial, school, and factory applications, as well as utility-grade home energy storage projects.

Which communication interfaces are supported?

The system supports multiple external communication interfaces, including Ethernet, CAN, and RS485 for seamless integration with management systems.
